Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: songhua
  • item: PTFE ROD
  • raw materials: 100% pure virgin PTFE
  • Density: 2.1g/cm3~2.3g/cm3
  • Temperature: -180c~+260c
  • tensile strength: >15.0Mpa
  • tear elongation: >150%
  • Volage: 10 KV/mm
  • fillers: carbon,bronze,glass,as order
  • Color: white,black,as order
  • Minimum Order Quantity: 500 Kilogram/Kilograms

Packaging & Delivery

Packaging Details: plastic bag,wooden case,or as order
Delivery Detail: 7-15days

Specifications

Plastic Extruded PTFE ROD
the most chemically resistant plastic
Easy to machine
Low coefficient of friction
Temperature

Plastic Extruded PTFE  ROD



our company:

HUZHOU SONGHUA RUBBER&PLASTIC CO.,LTD.which is one of the biggest enginering plastic products manufactory in china market for more than 20 years with good credit and competitive price.We can supply PTFE ROD,SHEET,SKIVED,TUBE,PIPE,FILM,etc,together with HDPE,PP,POM,PVC,NYLON ROD AND SHEET.70% of our products are exported to European,Middle-East,Australia and Asian etc.









 PTFE RODS description:

PTFE Rod is often chosen to produce bearings because of its very low friction and also for its free running ability. Because of its ability to conform to shape otherwise known as flow, PTFE Rod is used for seals in valves, this is because it can conform to shape and create a high specification valve seal. PTFE Rod can easily be machined but due to the surface softness, care must be taken in lathe jaws or high compressive loads, which may cause distortion. Another important element to remember regarding PTFE Rod is the coefficient of expansion due to heat changes; this can be uneven with PTFE and may cause distortion in components.

PTFE Rod,Teflon Rod of properties

· Being corrosion-resistant

· Non-stick

· Self-lubricating

· Good Insulating

· Never aging

· High and low temperature resistance

· Airproof

· Hight lubricity





PTFE Rod ,PTFE Bar of Properties:

PTFE Rod,Teflon Rod  Properties

Item

Data  Unit

Data

Density

g/m3

2.2~2.3

Tensile strength

MPa

15.0

Ultimate elongation (min)

%

150

Working Temp

°C

- 200 ~ 260

Melting point

°C

330

Produce Max. Temp

°C

390

Compressive strength 1% deformation

N/mm2

400-450

Elongation at break

%

210-400

Hardness

shoreD

50-60

Water absorption

%

0.01





PTFE Rod ,Teflon Bar,PTFE Bar of specifications:

ITEM

DIA(MM)

LENGTH(MM)

MATERIAL

Extruded PTFE Rod

5mm~200mm

300mm~2000mm

Virgin Material Grade and reclaimed materials

Molded PTFE Rod

110mm~400mm

200mm~1000mm

Virgin Material Grade and reclaimed materials

Filled PTFE Rod

5mm~400mm

300mm~2000mm

Virgin Material Grade and reclaimed materials





Choose us as the following reason:







About other problems can tell me:
